CDL02-40WS-3CCT-UD


Placeholder
Thumbnail
Downloads
CDL02-40WS-3CCT-UD-Product-Sheet.pdf
CLD02-40W-3CCT-UD (CDL02-4-R).ies
CLD02-40W-3CCT-UD (CDL02-4-S).ies
CLD02-40W-3CCT-UD (CDL02-4-R-WW).ies
CDL02-Installation-Instructions.pdf
CLD02-40W-3CCT-UD (CDL02-8-R).ies

Commercial Downlight Engine

Wattage Selectable l 3CCT l 120-347V
1 rating
Log in to view inventory availability and pricing Don't have an account? Sign up here.

Achieve your custom look with these sleek and easy-to-install, wattage selectable, colour tunable, commercial downlights

Twist and lock for an easy, tool-free reflector installation

Wattage selectable (27W / 34W / 40W)

Colour tunable (3000K / 3500K / 4000K)

120-347V universal driver with 4kV surge protection

Built-in junction box

70° beam angle

Recessed matte diffuser when paired with reflector (Reflector sold separately)

Product Number:
CDL02-40WS-3CCT-UD
Certifications Listed:
cUL, EnergyStar
Light Specifications
Color Temperature:
3000K/3500K/4000K
Initial Lumens:
3000lm
Efficacy:
75 LM/W
Beam Angle:
70°
Dimmable:
0-10V
CRI:
>80
Life (L70):
>50,000 hrs
Electrical Specifications
Watts:
27W/34W/40W
Voltage:
120-347V
IP Rating:
Damp Location
THD:
<20%%
Power Factor:
>0.9
Operating Temperature:
-20 °C to 50°C
Construction Specifications
Housing:
Aluminum
Finish Color:
Silver / White
Logistics
Carton Weight:
10 lbs
Carton Length:
14.0 in
Carton Width:
10.0 in
Carton Height:
7.0 in
Customer Reviews
  • Excellent product
    Clayton W.
    18-Jul-2022
    We have used these commercial fixtures in a few applications and they work great. Nice even light out put and nice finish look. We will definitely use these again.

Accessories

Product Description
For CDL02 Downlights
For CDL02 Downlights
For CDL02 Downlights
For CDL02 Downlights
For CDL02 Downlights

Related Products

Product Description
15W l 3CCT l 120-347V
20W l 3CCT l 120-347V
