FL05-450W-3P-3CCT-UD-BZ
12 avis
FLEX Series Area Light
350W/400W/450W | 3CCT | 120-347V | 44114-61020 lm
GTIN / UPC : 10845599012877
Code-barres : 845599012870
12 avis
Power selectable 350W/400W/450W
Colour selectable 3000K/4000K/5000K
120-347 universal driver
0-10V dimmable
Bronze powder coat finish
Rugged die cast aluminum housing
Photocell and sensor compatible
Easy field interchangeable optics (sold separately)
MOUNTING SOLD SEPARATELY
Certifications Listed:
cUL, DarkSky, DLCPremium, IK08
CSC DLC Number:
S-D6B0F9
CSC LED Warranty:
10 Year Warranty
Product Number:
FL05-450W-3P-3CCT-UD-BZ
Light Specifications
Beam Angle:
Type III
Colour Temperature:
3000K/4000K/5000K
CRI:
80+
Dimmable:
0-10V
Efficacy:
120.88 LM/W
Initial Lumens:
54397 lm
Life (L70):
>50,000 hrs
Electrical Specifications
Amperage:
4.5 A
IP Rating:
IP65
Operating Temperature:
-40°C to 45°C
Power Factor:
>0.9
THD:
<20%
Voltage:
120-347V
Watts:
350W/400W/450W
Construction Specifications
Finish:
Polyester Powder Coat
Finish Colour:
Bronze
Housing:
Die-Cast Aluminum
Power Cord Length:
78"
Logistics
Unit Weight:
16.7 lbs
Unit Length:
29.5 in
Unit Width:
14.0 in
Unit Height:
3.1 in
Qty per Master Carton:
1
Master Carton Weight:
19.1 lbs
Master Carton Length:
29.9 in
Master Carton Width:
15.1 in
Master Carton Height:
4.3 in
Qty per Skid:
81
