SDL-4RS-9W-5CCT-WH
SDL Slim Recessed Downlight
9W | 120V | 5CCT | 616-715 lm
GTIN / UPC : 10845599063084
Code-barres : 845599063087
Sleek and compact, the Solen series integrates easily into any ceiling, providing a flexible solution for everyday residential spaces!
TRIAC / ELV Dimming
Hinged driver door for quick installation and access
Pre-installed lever connectors for quick wiring
White trim standard with black and brushed nickel options available (sold separately)
4' and 10' extension cables available
Eco-friendly packaging
5CCT selectable
Enclosed design suitable for use in closets
Certifications Listed:
cETL, EnergyStar
CSC LED Warranty:
5 Year Warranty
Product Number:
SDL-4RS-9W-5CCT-WH
Light Specifications
Beam Angle:
120
Colour Temperature:
2700K/3000K/3500K/4000K/5000K
CRI:
80+
Efficacy:
78 LM/W
Initial Lumens:
700 lm
Life (L70):
>50,000 hrs
Electrical Specifications
Amperage:
0.1 A
IP Rating:
IP54
Operating Temperature:
-20°C to 40°C
Power Factor:
>0.9
THD:
<20%%
Voltage:
120V
Watts:
9W
Construction Specifications
Base:
Aluminum
Finish:
Powder Coat
Finish Colour:
White
Housing:
Polycarbonate
Power Cord Length:
13"
Logistics
Unit Weight:
0.551 lbs
Unit Length:
5.0 in
Unit Width:
5.0 in
Unit Height:
0.81 in
Qty per Carton:
1
Carton Weight:
0.595 lbs
Carton Length:
5.31 in
Carton Width:
5.31 in
Carton Height:
2.56 in
Qty per Master Carton:
18
Master Carton Weight:
14.0 lbs
Master Carton Length:
16.5 in
Master Carton Width:
11.2 in
Master Carton Height:
8.7 in
Qty per Skid:
1296
