VOL22-40W-3P-3CCT-UD
Volumetric Troffer
2' x 2' | 20W/30W/40W | 3CCT | 120-347V | 2760-5140 lm
GTIN / UPC : 10845599061165
Code-barres : 845599061168
Colour selectable (3000K/3500K/4000K)
Power selectable (20W/30W/40W)
Seismic mounting clips included
Measures 2' x 2'
120-347V universal driver
0-10V dimmable
Meets/exceeds DLC 5.1 glare standards for increased visual comfort
Certifications Listed:
cETL, DLC
CSC DLC Number:
S-6KDAG7
CSC LED Warranty:
5 Year Warranty
Product Number:
VOL22-40W-3P-3CCT-UD
Light Specifications
Colour Temperature:
3000K/3500K/4000K
CRI:
86
Dimmable:
0-10
Efficacy:
124 LM/W
Initial Lumens:
4714 lm
Life (L70):
>50,000 hrs
Electrical Specifications
IP Rating:
IP20
Operating Temperature:
-20°C to 40°C
Power Factor:
0.93
THD:
17%
Voltage:
120-347V
Watts:
20W/30W/40W
Construction Specifications
Finish Colour:
White
Housing:
Metal
Logistics
Unit Length:
23.74 in
Unit Width:
2.07 in
Unit Height:
23.74 in
Qty per Carton:
1
Qty per Master Carton:
2
Master Carton Weight:
6.4 lbs
Master Carton Length:
25.5 in
Master Carton Width:
5.5 in
Master Carton Height:
25.7 in
Qty per Skid:
96
