CP03-75W-3P-3CCT-UD-WH
3 reviews
CP03 Canopy Light
40W/60W/75W | 3CCT | 120-347V | 5269-9414 lm
GTIN / UPC: 10845599020575
Barcode: 845599020578
3 reviews
Check out our new Marquee Series Canopy Lights now available for order!
Power selectable (40W/60W/75W)
Colour selectable (3000K/4000K/5000K)
6kV surge protection
0-10V dimming
Faceted polycarbonate lens for superior glare control, fire, and vandal resistance
Universal 120-347V input
Dropped lens for improved beam angle allows for wider spacing of luminaires
Certifications Listed:
cUL, DLCPremium
CSC DLC Number:
S-BEXF8Q
CSC LED Warranty:
5 Year Warranty
Product Number:
CP03-75W-3P-3CCT-UD-WH
Light Specifications
Beam Angle:
110
Colour Temperature:
3000K/4000K/5000K
CRI:
82
Dimmable:
0-10
Efficacy:
123 LM/W
Initial Lumens:
8744 lm
Life (L70):
>54,000 hrs
Electrical Specifications
Amperage:
1.0 A
IP Rating:
IP65
Operating Temperature:
-40°C to 45°C
Power Factor:
0.9
THD:
15%
Voltage:
120-347V
Watts:
40W/60W/75W
Construction Specifications
Finish:
Powder Coat
Finish Colour:
White
Housing:
Aluminum Alloy
Mounting Type:
Surface
Logistics
Unit Weight:
7.41 lbs
Unit Length:
10.0 in
Unit Width:
10.0 in
Unit Height:
4.17 in
Qty per Carton:
1
Carton Weight:
7.62 lbs
Carton Length:
12.13 in
Carton Width:
6.22 in
Carton Height:
12.2 in
Qty per Master Carton:
2
Master Carton Weight:
12.6 lbs
Master Carton Length:
13.1 in
Master Carton Width:
12.7 in
Master Carton Height:
13.0 in
Qty per Skid:
126
