Power selectable 20W/30W/40W
3CCT selectable 3000K/4000K/5000K
120-347V universal driver
Built-in Photocell (unplug to bypass)
Motion Sensor compatible
DarkSky Approved when set to 3000K
Bronze
NOTE: The KWP-BKPL-XS-BZ and MS-KN01-BZ are required accessories (sold separately) when using optional Motion Sensors (MS01-PIR-TW-DC & MS04-MW-TW-DC)
Certifications Listed:
cUL
CSC LED Warranty:
10 Year Warranty
Product Number:
KWP-20W-3P-3CCT-UD-BZ
Light Specifications
Beam Angle:
Type II
Colour Temperature:
3000K/4000K/5000K
CRI:
80+
Dimmable:
0-10V
Efficacy:
150 LM/W
Initial Lumens:
2940 lm
Life (L70):
>50,000 hrs
Electrical Specifications
Amperage:
0.1 A
IP Rating:
IP65
Operating Temperature:
-40°C to 50°C
Power Factor:
0.9
THD:
25%
Voltage:
120-347V
Watts:
10W/15W/20W
Construction Specifications
Finish:
Powder Coat
Finish Colour:
Bronze
Housing:
Die-Cast Aluminum
Logistics
Unit Weight:
1.47 lbs
Unit Length:
6.07 in
Unit Width:
3.07 in
Unit Height:
5.56 in
Qty per Carton:
1
Carton Weight:
1.6 lbs
Carton Length:
6.26 in
Carton Width:
3.35 in
Carton Height:
5.71 in
Qty per Master Carton:
8
Master Carton Weight:
13.9 lbs
Master Carton Length:
13.2 in
Master Carton Width:
12.1 in
Master Carton Height:
7.6 in
Qty per Skid:
1056
GTIN / UPC:
10845599031687
Barcode:
845599031680
