AWP05-80W-3CCT-4P-UD
AWP05 Series Wall Pack
40W/50W/60W/80W | 3CCT | 120-347V | 6258-12226 lm
GTIN / UPC : 10845599031649
Code-barres : 845599031642
Power selectable (40W/50W/60W/80W)
3CCT selectable (3000K/4000K/5000K)
Built-in Photocell
Junction box mount with conduit entries
Built-in water drainage
UV-resistant polycarbonate refractor lens with type III distribution
Durable die-cast aluminum housing
Adjustable 0-90° for precise aiming
Certifications Listed:
cUL, DLCPremium, IK08
CSC DLC Number:
S-04YLW8
CSC LED Warranty:
10 Year Warranty
Product Number:
AWP05-80W-3CCT-4P-UD
Light Specifications
Colour Temperature:
3000K/4000K/5000K
CRI:
80+
Dimmable:
0-10
Efficacy:
150 LM/W
Initial Lumens:
12009 lm
Life (L70):
>50,000 hrs
Electrical Specifications
Amperage:
0.7 A
IP Rating:
IP65
Operating Temperature:
-40°C to 50°C
Power Factor:
0.90
THD:
<20%
Voltage:
120-347V
Watts:
40W/50W/60W/80W
Construction Specifications
Finish:
Powder Coat
Finish Colour:
Bronze
Housing:
Die-Cast Aluminum
Mounting Type:
Wall Mount
Battery Specifications
Battery Voltage:
0.00 V
Battery Amp Hours:
0.00 Ah
Logistics
Unit Weight:
4.19 lbs
Unit Length:
7.72 in
Unit Width:
5.8 in
Unit Height:
8.36 in
Qty per Carton:
1
Carton Weight:
4.85 lbs
Carton Length:
8.7 in
Carton Width:
6.9 in
Carton Height:
9.5 in
Qty per Master Carton:
1
Qty per Skid:
160
AWP05-80W-3CCT-4P-UD
AWP05 Series Wall Pack
40W/50W/60W/80W | 3CCT | 120-347V | 6258-12226 lm
GTIN / UPC : 10845599031649
Code-barres : 845599031642
