CWPS-120W-3P-3CCT-UD
1 avis
Slim Classic Wall Pack
80W/100W/120W | 3CCT | 120-347V | 10670-16420 lm
GTIN / UPC : 10845599031229
Code-barres : 845599031222
1 avis
Power selectable 80W/100W/120W
Colour selectable 3000K/4000K/5000K
Built-in photocell
120-347V universal driver
IP65 wet location rated
Classic look with a slim redesign and large footprint
Retro-friendly
Borosilicate glass lens resists thermal expansion, stress, and is chemical resistant
Non-yellowing lens
Certifications Listed:
cUL, DLCPremium, IK05
CSC DLC Number:
S-NWTC5D
CSC LED Warranty:
10 Year Warranty
Product Number:
CWPS-120W-3P-3CCT-UD
Light Specifications
Beam Angle:
105°
Colour Temperature:
3000K/4000K/5000K
CRI:
82
Dimmable:
0-10
Efficacy:
130.2 LM/W
Initial Lumens:
15571 lm
Life (L70):
>54,000 hrs
Electrical Specifications
Amperage:
1.3 A
IP Rating:
IP65
Operating Temperature:
-40°C to 45°C
Power Factor:
0.9
THD:
15%
Voltage:
120-347V
Watts:
80W/100W/120W
Construction Specifications
Finish:
Polyester Powder Coat
Finish Colour:
Bronze
Housing:
Die-Cast Aluminum
Logistics
Unit Weight:
12.76 lbs
Unit Length:
17.8 in
Unit Width:
12.75 in
Unit Height:
4.51 in
Qty per Master Carton:
1
Master Carton Weight:
15.6 lbs
Master Carton Length:
18.9 in
Master Carton Width:
14.7 in
Master Carton Height:
6.7 in
Qty per Skid:
78
