Power selectable 80W/100W/120W
Colour selectable 3000K/4000K/5000K
Built-in photocell
120-347V universal driver
IP65 wet location rated
Classic look with a slim redesign and large footprint
Retro-friendly
Borosilicate glass lens resists thermal expansion, stress, and is chemical resistant
Non-yellowing lens
Certifications:
cUL, DLCPremium, IK05
CSC DLC Number:
S-NWTC5D
Garantie CSC LED:
10 Year Warranty
Numéro de produit:
CWPS-120W-3P-3CCT-UD
Caractéristiques lumineuses
Angle du faisceau:
105°
Température de couleur:
3000 K/4000 K/5000 K
IRC:
82
Dimmable:
0-10
Efficacité:
130.2 LM/W
Lumens initiaux:
15571 lm
Durée de vie (L70):
>54,000 hrs
Caractéristiques électriques
Amperage:
1.3 A
Indice IP:
IP 65
Température de fonctionnement:
-40°C to 45°C
Power Factor:
0.9
DHT:
15%
Tension:
120-347V
Watts:
80W/100W/120W
Caractéristiques de construction
Finish:
Polyester Powder Coat
Couleur de finition:
Bronze
Boîtier:
Die-Cast Aluminum
Logistique
Poids unitaire:
12.76 lbs
Unit Length:
17.8 in
Unit Width:
12.75 in
Unit Height:
4.51 in
Qté par carton principal:
1
Poids du carton principal:
15.6 lbs
Longueur du carton principal:
18.9 in
Largeur du carton principal:
14.7 in
Hauteur du carton principal:
6.7 in
Qté par palette:
78
CUP:
845599031222
GTIN:
10845599031229
