SPT-900W-3P-50K-22D-UD-GR
Titan Sports Light
700W/800W/900W | 120-347V | 5000K | 119,000 - 153,000 lm
GTIN / UPC : 10845599013157
Code-barres : 845599013150
Remote driver capability with optional Remote Driver Mount sold separately
Power selectable with 3 power settings per fixture
Tool-free accessible driver box
High bay mount option
1000-hour salt spray endurance
Pre-installed Yoke Mount standard with additional mounting solutions sold separately
Built-in Photcell Receptacle
Certifications Listed:
cUL, IK08
CSC DLC Number:
S-WXHVZ4, S-SDD76H
Product Number:
SPT-900W-3P-50K-22D-UD-GR
Light Specifications
Beam Angle:
22°
Colour Temperature:
5000K
CRI:
70+
Dimmable:
0-10
Efficacy:
170 LM/W
Initial Lumens:
153000 lm
Life (L70):
>50,000 hrs
Electrical Specifications
Amperage:
7.5 A
IP Rating:
IP66
Operating Temperature:
-40°C to 45°C
Power Factor:
>0.9
THD:
<20%
Voltage:
120-347V
Watts:
700W/800W/900W
Construction Specifications
Finish:
Powder Coat
Finish Colour:
Grey
Housing:
Die-Cast Aluminum
Mounting Type:
Yoke Mount
Power Cord Length:
72"
Logistics
Unit Weight:
42.11 lbs
Unit Length:
20.71 in
Unit Width:
22.20 in
Unit Height:
12.83 in
Qty per Carton:
1
Qty per Master Carton:
1
Master Carton Weight:
47.8 lbs
Master Carton Length:
26.4 in
Master Carton Width:
24.0 in
Master Carton Height:
10.6 in
Qty per Skid:
14
