SP01B-500W-50K-30D-UD
1 review
Sports Stadium Light
500W l 5000K l 120-347V | 69937 lm
GTIN / UPC: 10845599011238
Barcode: 845599011231
1 review
Suitable for indoor/outdoor recreational facilities such as gymnasiums, stadiums, shipyards, airports, and high-mast lighting
0-10V dimmable
Complete with 30° optic lens (120° optic lens available - sold separately)
Instant start with no flickering or humming
Complete with yoke mount (slip fitter available - sold separately)
Certifications Listed:
cUL, DLCPremium
CSC DLC Number:
PLCORE03L4YK
CSC LED Warranty:
5 Year Warranty
Product Number:
SP01B-500W-50K-30D-UD
Light Specifications
Beam Angle:
30
Colour Temperature:
5000K
CRI:
70+
Dimmable:
0-10
Efficacy:
139.99 LM/W
Initial Lumens:
69937 lm
Life (L70):
>50,000 hrs
Electrical Specifications
IP Rating:
IP65
Operating Temperature:
-40°C to 45°C
Power Factor:
>0.9
THD:
<15%
Voltage:
120-347V
Watts:
500W
Construction Specifications
Finish Colour:
Black
Housing:
Aluminum Alloy
Mounting Type:
Yoke
Power Cord Length:
27"
Logistics
Unit Weight:
32 lbs
Qty per Master Carton:
1
Master Carton Weight:
37.6 lbs
Master Carton Length:
18.9 in
Master Carton Width:
18.9 in
Master Carton Height:
18.5 in
Qty per Skid:
25
