Power selectable 100W/125W/150W
3CCT Selectable 3000K/4000K/5000K
120-347V universal driver with 0-10V dimming
Mounting sold separately and required for use
3 distribution types per luminaire 5H5V/6H6V/7H6V
Built-in Photocell (switch off to disable)
IK07 and IP65 rated
Certifications:
cUL, DLCPremium, IK07
CSC DLC Number:
S-FWNWM8
Garantie CSC LED:
10 Year Warranty
Numéro de produit:
FLF-150W-3P-3CCT-3B-UD-BK
Caractéristiques lumineuses
Angle du faisceau:
7H6V
Température de couleur:
3000 K/4000 K/5000 K
IRC:
80+
Dimmable:
0-10V
Efficacité:
150 LM/W
Lumens initiaux:
22500 lm
Durée de vie (L70):
>50,000 hrs
Caractéristiques électriques
Amperage:
1.5 A
Indice IP:
IP 65
Température de fonctionnement:
-40°C to 50°C
Power Factor:
>0.9
DHT:
<20%
Tension:
120-347V
Watts:
100W/125W/150W
Caractéristiques de construction
Finish:
Powder Coat
Couleur de finition:
Black
Boîtier:
Die-Cast Aluminum
Power Cord Length:
23.62 "
Logistique
Poids unitaire:
10.14 lbs
Unit Length:
12.48 in
Unit Width:
10.55 in
Unit Height:
5.94 in
Qté par carton:
1
Carton Weight:
13 lbs
Carton Length:
15.5 in
Carton Width:
13.9 in
Carton Height:
8.46 in
Qté par palette:
96
CUP:
845599013020
GTIN:
10845599013027
