FLF-150W-3P-3CCT-3B-UD-BZ
Fusion Flood Light
100W/125W/150W l 3CCT l 120-347V | 15167-21936 lm
GTIN / UPC : 10845599013034
Code-barres : 845599013037
Power selectable 100W/125W/150W
3CCT Selectable 3000K/4000K/5000K
120-347V universal driver with 0-10V dimming
Mounting sold separately and required for use
3 distribution types per luminaire 5H5V/6H6V/7H6V
Built-in Photocell (switch off to disable)
IK07 and IP65 rated
Certifications Listed:
cUL, DLCPremium, IK07
CSC DLC Number:
S-FWNWM8
CSC LED Warranty:
10 Year Warranty
Product Number:
FLF-150W-3P-3CCT-3B-UD-BZ
Light Specifications
Beam Angle:
7H6V
Colour Temperature:
3000K/4000K/5000K
CRI:
80+
Dimmable:
0-10V
Efficacy:
150 LM/W
Initial Lumens:
22500 lm
Life (L70):
>50,000 hrs
Electrical Specifications
Amperage:
1.5 A
IP Rating:
IP65
Operating Temperature:
-40°C to 50°C
Power Factor:
>90
THD:
<20%
Voltage:
120-347V
Watts:
100W/125W/150W
Construction Specifications
Finish:
Polyester Powder Coat
Finish Colour:
Bronze
Housing:
Die-Cast Aluminum
Power Cord Length:
23.62"
Logistics
Unit Weight:
10.14 lbs
Unit Length:
12.48 in
Unit Width:
10.55 in
Unit Height:
5.94 in
Qty per Carton:
1
Carton Weight:
13 lbs
Carton Length:
15.5 in
Carton Width:
13.9 in
Carton Height:
8.46 in
Qty per Skid:
96
FLF-150W-3P-3CCT-3B-UD-BZ
Fusion Flood Light
100W/125W/150W l 3CCT l 120-347V | 15167-21936 lm
GTIN / UPC : 10845599013034
Code-barres : 845599013037
