FLF-80W-3P-3CCT-3B-UD-BK
Fusion Flood Light
40W/60W/80W l 3CCT l 120-347V | 7060-11243 lm
GTIN / UPC : 10845599013003
Code-barres : 845599013006
Power selectable 40W/60W/80W
3CCT Selectable 3000K/4000K/5000K
120-347V universal driver with 0-10V dimming
Mounting sold separately and required for use
3 distribution types per luminaire 5H5V/6H6V/7H6V
Built-in Photocell (switch off to disable)
IK07 and IP65 rated
Certifications Listed:
cUL, DLCPremium, IK07
CSC DLC Number:
S-32H9N1
CSC LED Warranty:
10 Year Warranty
Product Number:
FLF-80W-3P-3CCT-3B-UD-BK
Light Specifications
Colour Temperature:
3000K/4000K/5000K
CRI:
80+
Dimmable:
0-10
Efficacy:
134 LM/W
Initial Lumens:
10694 lm
Life (L70):
>50,000 hrs
Electrical Specifications
Amperage:
0.8 A
IP Rating:
IP65
Operating Temperature:
-40°C to 50°C
Power Factor:
>0.9
THD:
<20%
Voltage:
120-347V
Watts:
40W/60W/80W
Construction Specifications
Finish:
Polyester Powder Coat
Finish Colour:
Black
Housing:
Die-Cast Aluminum
Power Cord Length:
23.62"
Logistics
Unit Weight:
6.6 lbs
Unit Length:
9.72 in
Unit Width:
9.25 in
Unit Height:
5.12 in
Qty per Carton:
1
Carton Weight:
8.6 lbs
Carton Length:
12.6 in
Carton Width:
11.4 in
Carton Height:
7.1 in
Qty per Skid:
144
