ST2B-20W-3CCT-UD
6 avis
2' Strip Light
20W | 3CCT | 120-347V | 2900 lm
GTIN / UPC : 10845599061202
Code-barres : 845599061205
6 avis
Ideal for shops, cove lighting, and general area lighting
3CCT selectable (3500K/4000K/5000K)
Designed for a quick and easy installation
Opens and closes without the use of tools
Light engine drops on aircraft cables for ease of installation
Row mountable with optional Row Mount Kit (sold separately)
2' length
Certifications Listed:
cUL, DLC, DLCPremium, IK08
CSC DLC Number:
S-L4CFW3, S-MJE0AV
CSC LED Warranty:
5 Year Warranty
Product Number:
ST2B-20W-3CCT-UD
Light Specifications
Beam Angle:
120
Colour Temperature:
3500K/4000K/5000K
CRI:
85
Dimmable:
0-10
Efficacy:
145 LM/W
Initial Lumens:
2900 lm
Life (L70):
>50,000 hrs
Electrical Specifications
Amperage:
0.6 A
IP Rating:
IP20
Operating Temperature:
-20°C to 45°C
Power Factor:
0.93
THD:
14.4%
Voltage:
120-347V
Watts:
20W
Construction Specifications
Finish Colour:
White
Housing:
Colour Coated Steel Plate
Mounting Type:
Surface or Pendant
Logistics
Unit Weight:
1.74 lbs
Unit Length:
23.97 in
Unit Width:
2.95 in
Unit Height:
3.26 in
Qty per Carton:
1
Carton Weight:
2.07 lbs
Carton Length:
24.4 in
Carton Width:
3.2 in
Carton Height:
3.5 in
Qty per Master Carton:
8
Master Carton Weight:
16.5 lbs
Master Carton Length:
25.0 in
Master Carton Width:
13.8 in
Master Carton Height:
7.9 in
Qty per Skid:
528
