VT4-105W-4P-3CCT-UD
12 avis
NEMA 4X VT4 Vapour Tight
70W/80W/90W/105W | 3CCT | 120-347V | 9990-14783 lm
GTIN / UPC : 10845599020599
Code-barres : 845599020592
12 avis
Power selectable 70W / 80W / 90W / 105W
Colour selectable 3500W / 4000K / 5000K
120-347 Universal Driver
Polycarbonate low glare lens
One piece gear tray for quick access to driver and accessories
Stainless steel spring clips
1/2'' NPT entry
IK10 vandal resistant
NSF rated
NEMA4X
Certifications Listed:
cUL, DLCPremium, IK10, NSF
CSC DLC Number:
S-FH4Q07, S-0ZL3JL
CSC LED Warranty:
5 Year Warranty
Product Number:
VT4-105W-4P-3CCT-UD
Light Specifications
Beam Angle:
120°
Colour Temperature:
3500K/4000K/5000K
CRI:
85
Dimmable:
0-10V
Efficacy:
135 LM/W
Initial Lumens:
13981 lm
Life (L70):
>50,000 hrs
Electrical Specifications
Amperage:
1.1 A
IP Rating:
IP67
Operating Temperature:
-40°C to 40°C
Power Factor:
0.93
THD:
14.3%
Voltage:
120-347V
Watts:
70W/80W/90W/105W
Construction Specifications
Finish Colour:
White
Housing:
Polycarbonate
Mounting Type:
Surface or Pendant
Logistics
Unit Weight:
14.6 lbs
Unit Length:
50.0 in
Unit Width:
10.0 in
Unit Height:
4.7 in
Qty per Master Carton:
1
Master Carton Weight:
17.0 lbs
Master Carton Length:
51.0 in
Master Carton Width:
10.8 in
Master Carton Height:
5.5 in
Qty per Skid:
60
